  • DGO9767CD MICROPHONE
      • DGO9767CD MICROPHONE
    Product Details

    Model No.DGO9767CD
    Sensivity(0dB=1v/μbar,1KHz)-30dB ~ -44dBOperation   Voltage(Max./Std.)4.5V
     Impedance Low impedance(2.2KΩ-30%)Resistance(RL):2.2KΩ
    Directivity Omni-directionalCurrent Consumption:Max.0.5.mA
    Frequency20~16,000HzSensitivity ReductionWithin -3dB at 3V
    Max.operation voltage10VS/N RatioMore than 60dB
